Promax ST 180

Specifications

  • 50 - 70 - 110 m³/hr output capacities
  • Choices avaible for pan mixer,twin shaft or single shaft mixers
  • Options are avaible for 4 sectioned aggregate hopper for the capacities from 120 m3 up to 160 m3
  • Special design for different territories and and demands
  • Fully automatic, computer and operator panel controlled operation
  • Generator (optional)
SPECIFICATIONS UN T/M
Plant Capacity
Compacted Concrete Capacity
m3/h
180
Mixer Specifications
Mixer Types
Twin Shaft
Mixer Capacity
lt
4500
Dry Capacity
lt
6750
Motor Power
kW
2×90 Single
Aggregate Hopper
4 Bins
m3
2x3x30
Mixer Conveyor Band
Width
mm
1200
Length
mm
35000
Motor Power
kW
2×11
Aggregate Weighing Belt
Width
mm
1200
Length
mm
2×8250
Motor Power
kW
2×11
Weighbridges
Aggregate Weighing Group
kg
2×6000
Cement Weighing Group
kg
1500
Water Weighing Group
lt
1100
Additives Weighing Group
kg
40
Cement Silo and Screw Conveyor
Diameter ø
mm
273
Length
mm
11500
Motor Power
kW
15
Fixed Cement Silo
Capacity (Welded or Bolted)
ton
75-100-200
Silo Quantity
adet
1,2,3,4
Air Compressor
Capacity  (Welded or Bolted)
lt/dak
1360
Working Pressure
bar
7-8
Motor Power
kW
5,5
Water Pump
Pump
m3/h
100
Motor Power
kW
11
